Product Overview
Eaton Wiring Devices 60W48DPLXBK Recp Duplex WT 20A 250V 2P3W Str BK
Eaton Arrow Hart watertight straight blade duplex receptacle, #18-10 AWG, 20A, Industrial, Panel, 250V, Back wire, Black, Nickel-plated brass, IP66, Glass filled Nylon, 6-20R, Duplex, Screw, Glass-filled nylon, Core pack
Arrow Hart's broad line of straight blade watertight devices provide superior watertight protection. These versatile products are ideal for food processing plants, oil refineries or chemical processing plants — anywhere that moisture, dirt or corrosive elements may be a factor.
| Allowable Wire Size | #18-10 AWG |
| Amperage Rating | 20 A |
| Application | Industrial |
| Color | Black |
| Connection Type | Screw |
| Contact Material | Nickel plated brass |
| Design Type | Straight blade |
| Device Grade | Watertight special use |
| Device Type | Receptacle |
| Environmental Conditions | Damp/Wet |
| Environmental Resistance | IP66 |
| Face/Body Material | Glass filled Nylon |
| Material | Glass-filled nylon |
| Mounting method | Panel |
| Mounting Type | Panel |
| Nema Configuration | 6-20R |
| Number Of Poles | Two-pole |
| Number Of Wires | 3 |
| Packaging type | Core pack |
| Receptacle Type | Duplex |
| Style Type | Standard |
| Type | Complex environment |
| Voltage Rating | 250V |
| Wiring Method | Back Wire |
| Length | 3.62 IN |
| Width | 4.25 IN |
| Height | 4.63 IN |
| Volume | 71.233 CI |
| Weight | 1.24 LB |
| Length | 3.62 IN |
| Width | 4.25 IN |
| Height | 4.63 IN |
|
