Product Overview
Eaton Wiring Devices 9965PWBK Plug WT 20A 125/250V 3P3W H/L BK
Eaton Arrow Hart watertight locking plug, #18-10 AWG, 20A, Industrial, 125/250V, Black, Watertight, Three-pole, Three-wire, non-grounding, Santoprene thermoplastic elastomeric, 0.36 to 0.84 in
Eaton's Arrow Hart watertight locking devices utilize a unique, robust design and superior materials to provide watertight security in harsh environments.
Allowable Wire Size | #18-10 AWG |
Amperage Rating | 20 A |
Application | Industrial |
Color | Black |
Contact Material | Nickel plated brass |
Cord Diameter | 0.36-0.84 in |
Design Type | Watertight locking plug |
Device Grade | Extra heavy-duty industrial specification grade |
Environmental Resistance | NEMA 6 | IP67 | NEMA 4X | NEMA 6P | NEMA 4 |
Face/Body Material | Nylon |
Material | Santoprene thermoplastic elastomeric |
Nema Configuration | Non-NEMA |
Number Of Poles | Three-pole |
Number Of Wires | Non-grounding | 3 |
Special Features | Watertight |
Torque rating | 14-16 lbf-inch |
Type | Locking plug |
Voltage Rating | 125/250 V |
Wiring Method | Back |
Length | 6.75 IN |
Width | 4.59 IN |
Height | 4.03 IN |
Volume | 124.859 CI |
Weight | 0.585 LB |
Length | 6.75 IN |
Width | 4.59 IN |
Height | 4.03 IN |
Weight | 0.585 LB |
Certifications
- cULus Listed
