Product Overview
Mars 00117 RS4BEB9E12 9W 115V 1550RPM REV
Motor Type
PSC
Enclosure
TEAO
H.P. (Max.)
9 Watt
Voltage
115
Speeds
1
Hz
60
Rotation
CW/CCW
RPM Range
1550
NEMA Frame Size
51
Phase
Single
Standards
UL/CSA
FLA
0.26
Mount
Unit Bearing
Bearing
Cast Iron Unit Bearing
Shaft Length Inches
0.425
Shaft Dia Inches
1/4
Thermal Protection
Yes
Ambient Deg C
40
Ins. Class
Class A
Capacitor Included
Internal
Brand
EM&S
Pack Qty
1
Case Qty
8
Pallet Qty
280
Length
6.60 in.
Width
4.30 in.
Height
4.20 in.
Weight
3.0500 lbs
Harmonized Tariff Code
8501106020
UPC
685744001171
Country of Origin Code
US
Country of Origin Name
United States
