Product Overview
Mars 10313 1/4HP 1725RPM 115/208-230V Replaces Marathon B313
Motor Type
Cap Start
Enclosure
Dripproof
H.P. (Max.)
1/4
Voltage
115/208-230
Speeds
1
Hz
60
Rotation
REV
RPM Range
1725
NEMA Frame Size
48YZ
Phase
Single
Standards
cULus
FLA
5.0/2.4-2.5
Mount
Resilient Base
Bearing
Ball
Shaft Length Inches
1.85
Shaft Dia Inches
1/2
Thermal Protection
Auto
Ambient Deg C
40
Ins. Class
Class B
Capacitor Included
Yes
Replaces
C196L, RL1203A, D12CPA2P49, 100109.00, C196, B313
Brand
MARS
Pack Qty
1
Case Qty
1
Pallet Qty
80
Length
14.70 in.
Width
6.90 in.
Height
8.80 in.
Weight
16.8500 lbs
Harmonized Tariff Code
8501404040
UPC
685744103134
Country of Origin Code
CN
Country of Origin Name
China
| MFG Name | MFG # |
| Baldor | RL1203A |
| Century/AO Smith | C196L |
| US Motors/Emerson | D12CPA2P49 |
| Leeson | 100109 |
| Magnetek | C196 |
| Marathon | B313 |
